DONJOY Sanitary one way check valve C Type High clean non-return valve

Name: DONJOY Sanitary one way check valve C Type High clean non-return valve
Brand: DONJOY
Availability: InStock
Rating: 5 (6 reviews)

0 đánh giá

Còn hàng

Liên hệ

Tư vấn giá tốt nhất

DONJOY Sanitary one way check valve C Type High clean non-return valve

FOB Price: USD 23.00-26.00 / pieces
Min order:2 pieces
Accept Min order: Yes
Supply Ability:1000 pieces / Month
Country of Origin: NingboTop of Form Bottom o

Product Description

Structure: Check
Power: Manual
Temperature of Media: Medium Temperature
Place of Origin: CN;ZHE
Media: Food, Beer, Beverage, Dairy
Port Size:1"-4"or DN25-DN100
Brand Name: DONJOY
Application: General
Type: ACCESS VALVES

DONJOY Weld Non return One Way Check Valve

Product structure

Technical Parameters

Product Name:	Weld Non-return One Way Check Valve
Valve Body Material:	SS304 or SS316L
Seal Material:	EPDM
Max. Working Pressure:	10Bar
Opening pressure:	0.1-0.3bar
Max. Working Temperature:	120 degree C
Availably size:	DN15-DN100 or 1/2"- 4"
Availably connection:	Thread,Weld,Clamp
Availably standard:	DIN,SMS,3A
Certificate:	FDA,CE

Dimensions

DIN

SIZE	H	D1	D2	D
DN25	65	28	25	70
DN32	65	34	31	70
DN40	65	40	37	82
DN50	74	52	49	97
DN65	85	70	66	118
DN80	93	85	81	138
DN100	103	104	100	158

INCH

SIZE	H	D1	D2	D
1’	65	25.4	22.4	70
1 1/4’	65	31.8	28.8	70
1 1/2'	65	38.1	35.1	82
2’	74	50.8	47.8	97
2 1/2’	85	63.5	59.5	118
3’	93	76.2	72.2	138
3 1 /2’	93	89	85	138
4’	103	101.6	97.6	158
